5KMSS-08XXXXL02

Products Category

5KMSS-08XXXXL02

Micro Sim Card Push-Pull Type 08P H=1.5

Specification:

Current Rating: 1.0 AMP
Voltage Rating: 30VRMS
Insulation Resistance: 1000MΩ Min.
Contact Resistance: 50mΩ Max.
Dielectric Voltage: 500V DC
Operation Temperature: -40°C to +85°C

Material

Housing :LCP, UL94V-0, Black
Contact : Copper Alloy

3D Model

Order / Inquiry Information:

×
