6SDDR02-1111XXXXXK01

DIP Switch 2.54mm DIP Right Angle Type H=9.9mm

Specification:

DIELECTRIC STRENGTH: 500VAC/1 MINUTE
RATING:SWITCHING: 25mA,24VDC
NON-SWITCHING: 100mA,50VDC
CONTACT RESISTANCE: INITIAL: 50mΩ MAX, AFTER LIFE TEST: 100mΩ MAX

Materials

BASE:PBT,UL94V-0
TERMINAL:PHOSPHOR BRONZE,GOLD PLATED

3D Model

Order / Inquiry Information:

×
